 Using UTL_TCP to send
E-Mail from PL/SQL with Oracle 8.1.6
The UTL_TCP is a TPC/IP package that provides PL/SQL procedures to support simple
TCP/IP-based communications between servers and the outside world. It is used by the
SMTP package, to implement Oracle server-based clients for the internet email protocol.
For more information see: Oracle8i Supplied PL/SQL Packages Reference Release 2
(8.1.6).
The following procedure SEND_MAIL can be used to send an E-Mail directly from the
database.
CREATE OR REPLACE PROCEDURE send_mail (
msg_from varchar2 := 'martin.zahn@akadia.com',
msg_to varchar2 := 'martin.zahn@akadia.com',
msg_subject varchar2 := 'Message from PL/SQL daemon',
msg_text varchar2 := 'Automatically send by PL/SQL
daemon')
IS
conn
utl_tcp.connection;
rc
integer;
mailhost varchar2(30) := 'rabbit.akadia.com';
BEGIN
conn := utl_tcp.open_connection(mailhost,25); -- open the
SMTP port
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
rc := utl_tcp.write_line(conn, 'HELO '||mailhost);
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
rc := utl_tcp.write_line(conn, 'MAIL FROM: '||msg_from);
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
rc := utl_tcp.write_line(conn, 'RCPT TO: '||msg_to);
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
rc := utl_tcp.write_line(conn, 'DATA'); -- Start message
body
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
rc := utl_tcp.write_line(conn, 'Subject: '||msg_subject);
rc := utl_tcp.write_line(conn, '');
rc := utl_tcp.write_line(conn, msg_text);
rc := utl_tcp.write_line(conn, '.'); -- End of
message body
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
rc := utl_tcp.write_line(conn, 'QUIT');
dbms_output.put_line(utl_tcp.get_line(conn, TRUE));
utl_tcp.close_connection(conn); --
Close the connection
EXCEPTION
when others then
raise_application_error(-20000,
'Unable to send E-mail message from pl/sql procedure');
END;
/
Examples
set serveroutput on
exec send_mail();
exec send_mail(msg_to =>'martin.zahn@akadia.com');
exec send_mail(msg_to =>'martin.zahn@akadia.com',
msg_text=>'How to send E-Mail from PL/SQL');
Show Oracle Version and installed
Options
The data dictionary views V$OPTION and V$VERSION can be used to get the current Oracle
version and the installed options. Click here for
the Script.
select banner
from sys.v$version;
select parameter
from sys.v$option
where value = 'TRUE';
select parameter
from sys.v$option
where value <> 'TRUE';
begin
dbms_output.put_line('Specific Port Information:
'||dbms_utility.port_string);
end;
/
Here is the produced Output from the Script:
Oracle Version:
BANNER
----------------------------------------------------------------
Oracle8i Enterprise Edition Release 8.1.5.0.0 - Production
PL/SQL Release 8.1.5.0.0 - Production
CORE Version 8.1.5.0.0 - Production
TNS for 32-bit Windows: Version 8.1.5.0.0 - Production
NLSRTL Version 3.4.0.0.0 - Production
Installed Options:
PARAMETER
----------------------------------------------------------------
Objects
Advanced replication
Bit-mapped indexes
Connection multiplexing
Connection pooling
Database queuing
Incremental backup and recovery
Instead-of triggers
Parallel backup and recovery
Parallel execution
Parallel load
Point-in-time tablespace recovery
Fine-grained access control
N-Tier authentication/authorization
Function-based indexes
Plan Stability
Online Index Build
Coalesce Index
Managed Standby
Materialized view rewrite
Materialized view warehouse refresh
Database resource manager
Spatial
Visual Information Retrieval
Export transportable tablespaces
Transparent Application Failover
Fast-Start Fault Recovery
Sample Scan
Duplexed backups
Java
Not Installed Options:
PARAMETER
----------------------------------------------------------------
Partitioning
Parallel Server
Specific Port Information: IBMPC/WIN_NT-8.1.0
Oracle 8i temporary Tables
A temporary table has a definition or structure that persists like that of a regular
table, but the data it contains exists only for the duration of a transaction or
session. Oracle8i allows you to create temporary tables to hold
session-private data. You specify whether the data is specific to a session or to a
transaction.
There are two options: Delete rows after commit or Delete rows after exit session.
create global temporary table mytemp (a date)
on commit delete rows -- Delete rows after commit
/
Show Status of the temporary table
select table_name, temporary, duration
from user_tables
where table_name = 'MYTEMP
/
Rows exists after insert
insert into mytemp values (sysdate);
select * from mytemp;
Inserted rows are missing after commit
commit;
select * from mytemp;
Avoid REVERSE KEY index together
with a FOREIGN Key
This alert comes from the oracle support.
Reverse key index on foreign key column allows deletion of parent key !
The FOREIGN KEY integrity constraint is provided to define and ensure the integrity of
a parent-child relationship between two tables. It requires that each value in a
column, or a set of columns match a value in a related (parent) table's UNIQUE or
PRIMARY KEY. FOREIGN KEY integrity constraints also define referential integrity
actions such as ON DELETE CASCADE which specifies that upon the deletion of the row in
the parent table, all corresponding rows in the referential (child) tables will be
deleted as well. If the ON DELETE CASCADE option is not specified for the FOREIGN KEY
constraint, the deletion of the row from the parent table is prevented with an error
message signalling the presence of corresponding rows in a child table.
If, however, a REVERSE KEY index is created on the column(s) defined in the FOREIGN KEY
integrity constraint, the deletion of the row in the parent table is allowed to proceed
without error, thereby leaving orphaned rows in the corresponding child table(s). If
the FOREIGN KEY was created with the ON DELETE CASCADE option, this directive is
ignored and the corresponding rows in the child table are not deleted.
Likelihood of Occurence
If you have defined a REVERSE KEY index on column(s) designated as a FOREIGN KEY
constraint and have deleted rows from the parent table, then it is likely that you will
have orphaned rows in the child table.
There are no error messages generated unless you disable and attempt to
re-enable the FOREIGN KEY constraint. If orphaned rows exist in the child table, you
will receive an ORA-02291 error message listing the name of the FOREIGN KEY constraint.
"ORA-02291:integrity constraint (SCOT7.FK-DEPTNO),violated-parent key not found"
Inserting in two or more tables with
SQL*Loader
If you want to load data from an ASCII or EBCDIC file into an Oracle Database --
SQL*Loader is the tool. In this article we want to show, how to distribute the rows in
the file in two tables depending on a value at a specified character position in the
file.
As an example, insert the row in table A if the value ra is 2 on position 7, insert
the row in table B if ra is 1 (see the following figure).
You need the following SQL*Loader controlfile to accomplish this task.
OPTIONS (SKIP=1)
LOAD DATA
CHARACTERSET WE8EBCDIC500
INFILE '$BOTENFILE' "fix 86"
BADFILE '$BOTENFILE.bad'
DISCARDFILE '$BOTENFILE.dsc'
REPLACE
INTO TABLE B
WHEN ra = X'F1'
(
astrnr POSITION (1:6) INTEGER EXTERNAL,
ra POSITION (7:7)
INTEGER EXTERNAL,
mc POSITION (8:8) INTEGER
EXTERNAL,
astrg POSITION (9:36) CHAR,
astrgk POSITION (37:61) CHAR
"UPPER(LTRIM(RTRIM(:astrgk)))",
astamm POSITION (62:71) CHAR,
aadrplz POSITION (72:77) INTEGER EXTERNAL,
astrart POSITION (78:79) INTEGER EXTERNAL,
apra POSITION (80:81) INTEGER EXTERNAL,
asprc POSITION (82:82) INTEGER EXTERNAL,
gplz POSITION (83:86) INTEGER EXTERNAL,
line SEQUENCE (1,1)
)
INTO TABLE A
WHEN ra = X'F2'
(
astrnr POSITION (1:6) INTEGER EXTERNAL,
ra POSITION (7:7)
INTEGER EXTERNAL,
abzart POSITION (8:8) INTEGER EXTERNAL,
abbez POSITION (9:11) CHAR
"(LTRIM(RTRIM(:abbez)))",
ahnrvn POSITION (12:15) INTEGER EXTERNAL,
ahnrva POSITION (16:17) CHAR "(LTRIM(RTRIM(:ahnrva)))",
ahnrbn POSITION (18:21) INTEGER EXTERNAL,
ahnrba POSITION (22:23) CHAR "(LTRIM(RTRIM(:ahnrba)))",
atc POSITION (24:24) CHAR,
line SEQUENCE (1,1)
)
The first line in the EBCDIC file is skipped OPTIONS (SKIP=1). The most interesting
part is the WHEN clause. The attribute "ra" is the single character that has the value
specified by hex-byte in the character encoding schema, such as X ' F1 '
(equivalent to 241 decimal), "X" must be uppercase. Due to National Language Support
NLS requirements, hex 00 cannot be used (See Oracle 8 Utilities Guide).
Avoid Rollback Segement
Problems with huge Updates / Deletes
If you have to UPDATE or DELETE a huge number of rows, you may encounter problems with
Rollback Segmets. One solution is to COMMIT after sets of n Rows, as the next example
shows.
declare
i number := 0;
n numner := 1000;
--
-- Lock the Rows for the UPDATE
--
cursor s1 is SELECT * FROM tab1
WHERE col1 = 'value1'
FOR UPDATE;
begin
for c1 in s1 loop
update tab1 set col1 = 'value2'
where current
of s1;
--
-- Commit after every n rows
--
i := 1 + 1;
if i > n then
commit;
i := 0;
end if;
end loop;
commit;
end;
/
Special characters needs 2 bytes in UTF8
If you want to import a dump file created by e.g. WE81SO8859P1 character set into UTF8
you can get an ORA-1401 Truncating Data Too Long for a Column. You can prevent this
message by increasing the size of your VARCHAR2 fields, because a special character
like umlauts needs 2 bytes in UTF8 and e.g. one byte in WE81SO8859P1. This means
that you must resize all your VARCHAR2 fields if you want to import VARCHAR2 fields
with umlauts.
How to set SYS password in Oracle for
NT ?
-
Run the Windows NT Registry editor regedt32
-
Make the HKEY_LOCAL_MACHINE window of the Registry editor the active window.
In the tree view, open the Software folder, then the ORACLE folder.
-
The correct location of the password file for each database appears in the
right-hand pane of the Registry editor. The format appears as
ORA_<SID>_PWFILE, followed by the password file location where <SID> is
the name of the Oracle database or the standard folder $ORACLE_HOME/database
filename PWD<SID>.ora
orapwd file=<fname> password=<password> entries=<users>
where:
file name of password file (mand)
password password for SYS and INTERNAL (mand)
entries maximum number of distinct DBA and OPERs (opt)
There are no spaces around the equal-to (=) character, e.g.
orapwd file=passwd.ora password=manager entries=10
After you have created the password file, you can relocate it as you choose. After
relocating the
password file, you must reset the appropriate environment variables to the new
pathname (check ORA_<SID>_PWFILE in registry), reboot your machine. If you
receive the file full error (ORA-1996) when you try to grant SYSDBA or SYSOPER system
privileges to a user, you must create a larger password file and re-grant the
privileges to all of the users. In 8.1.5 the str<SID>.cmd file doesn't exist
anymore and just one service handle all database actions, like
Automatic startup, shutdown, pfile, etc.
How to avoid having
remaining characters filled with blanks?
You are spooling a file with SQL*PLUS and want to avoid having remaining
characters filled with blanks or tabs. This may happen if you have set LINESIZE 500 and
your table rows are only 100 in size. The resulting script will not have the correct
format although the display on the screen will look correct. Another situation when
this may happen is if you are dumping a table to a comma delimited ASCII file to be
used with SQL LOADER. The line length is likely to be padded with blanks and will
dramatically increase the size of the file. Use the TRIMSPOOL ON command at the
beginning of your SQL script. This will trim the unneeded spaces in your file.
How to split Export or
standard output into smaller pieces ?
If you want to export the whole oracle database, or create a TAR archive of one of your
filesystem, you may reach a filesize which is bigger than 2 GB. On some unix
filesystems this is the maximal size for one single file. Or you want to distribute
your software release over the internet, then you usually create a TAR file which can
be downloaded. For your customers it may be helpful to download several small chunks
than one huge file. To accomplish these tasks you need split and often a
named pipe.
-
Create a named pipe
mknod tar_pipe p
-
Write to the named pipe as the first process
tar cvf tar_pipe <tar_directory>
&
-
Read from the named pipe as the second process
split -b 100k tar_pipe tar_split_
Now you have several files
-rw-r--r-- 1 root root 102400 Apr 24 12:10
tar_split_aa
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ab
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ac
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ad
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ae
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_af
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ag
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ah
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ai
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_aj
-rw-r--r-- 1 root root 102400 Apr 24 12:10 tar_split_ak
-
Concatenate the files and recreate tar_directory
cat tar_split_* | tar xvf -
-
Create a named pipe
mknod export_pipe p
-
Read from the named pipe as the first process
split -b 100k export_pipe full_export_ &
-
Export to the named pipe
exp userid=system/... full=y file=export_pipe
rm export_pipe
-
Import the database again
mknod import_pipe p
cat full_export_* > import_pipe &
imp userid=system/... full=y file=import_pipe
rm import_pipe
How to remove the default value from a
column ?
If you want to remove the default value for a column which already has a default value,
use the following two equivalent statements in Oracle8i (Note: in Oracle 7/8 they are
not equivalent).
ALTER TABLE address MODIFY (name DEFAULT NULL);
ALTER TABLE address MODIFY (name VARCHAR2(20) DEFAULT NULL);
Create table ADDRESS, then set a default value for column NAME.
CREATE TABLE address (
id NUMBER(5),
name VARCHAR2(20)
);
ALTER TABLE address MODIFY (name VARCHAR2(20) DEFAULT 'Unknown');
Check the default value in the data dictionary
COLUMN column_name FORMAT A10
COLUMN data_default FORMAT A10
SELECT column_name,
data_default,
data_length
FROM user_tab_columns
WHERE table_name = 'ADDRESS';
COLUMN_NAM DATA_DEFAU DATA_LENGTH
---------- ---------- -----------
ID
22
NAME
'Unknown' 20
Remove default value and check again
ALTER TABLE address MODIFY (name DEFAULT NULL);
COLUMN_NAM DATA_DEFAU DATA_LENGTH
---------- ---------- -----------
ID
22
NAME
NULL
20
ALTER TABLE address MODIFY (name VARCHAR2(20) DEFAULT NULL);
COLUMN_NAM DATA_DEFAU DATA_LENGTH
---------- ---------- -----------
ID
22
NAME
NULL
20
The table USER_TAB_COLUMNS show a NULL string irrespective of weather a datatype is
specified in the table modify statement or not. In Oracle7 and 8 a blank null is stored
when you use ALTER TABLE address MODIFY (name DEFAULT NULL);
How to avoid performance
disaster with PL/SQL tables ?
Last week, we have been called to verify an application written in PL/SQL, with a poor
performance and a lot of CPU consuming. The application fetches about 100'000 rows from
the database into a PL/SQL table for further processing. The PL/SQL table fits
completely into the memory, no swapping takes place. A closer look shows, that for each
processing cycle a procedure was called with the PL/SQL table as an argument -- here
we found the performance disaster -- in PL/SQL arguments are passed by value, that
means, the whole table was copied for each cycle !
First, we want to show a small example (Example 1) with this performance bottleneck --
DO NOT USE IT IN YOUR APPLICATION -- it's just a demonstration. Next we will show you,
how to avoid this situation in Oracle7/8 (Example 2) and at last we will show you the
NOCOPY hint in Oracle8i (Example 3).
The Procedure run_local uses local declaration of table emp_tab. For each
call of process_local, the full table emp_tab will be copied to the procedure and
return after processing (IN OUT definition), the content of the table could be changed.
Never do it in that way !
The procedure run_global uses global declaration of table emp_tab. The
procedure
uses the global definition of emp_tab, therefore no argument passing is necesary.
This procedure runs much faster, but we do not like like global variables ...
CREATE OR REPLACE
PACKAGE BODY plsql_tab IS
--
TYPE tab_type IS TABLE OF emp%ROWTYPE
INDEX BY BINARY_INTEGER;
g_emp_tab tab_type;
--
NofRuns CONSTANT NUMBER := 10;
NofRecords CONSTANT NUMBER := 9999;
--
-- Local usage
--
PROCEDURE process_local (p_emp_tab IN OUT
tab_type) IS
-- Parameter p_emp_tab is defined as IN OUT,
-- table emp_tab could be changed
i BINARY_INTEGER;
BEGIN
-- Parse EMP table
i := p_emp_tab.FIRST;
IF (NOT i IS NULL) THEN
LOOP
-- Do something
...
dbms_output.put(p_emp_tab(i).empno);
dbms_output.put_line(' ' ||
p_emp_tab(i).ename);
-- Get next
record
i := p_emp_tab.NEXT(i);
EXIT WHEN (i IS NULL);
END LOOP;
END IF;
END;
--
PROCEDURE run_local IS
l_emp_tab tab_type;
l_emp_rec emp%ROWTYPE;
BEGIN
-- Initialize local table
FOR i IN 1 .. NofRecords LOOP
l_emp_rec.empno := i;
l_emp_rec.ename := 'NEW';
l_emp_tab(i) := l_emp_rec;
END LOOP;
-- Process local table, for each cycle the
PL/SQL table is
-- put and fetch on the argument stack
FOR i IN 1 .. NofRuns LOOP
process_local
(l_emp_tab);
END LOOP;
END;
--
-- Global usage
--
PROCEDURE process_global IS
i BINARY_INTEGER;
BEGIN
-- Parse EMP table
i := g_emp_tab.FIRST;
IF (NOT i IS NULL) THEN
LOOP
-- Do something
...
dbms_output.put(g_emp_tab(i).empno);
dbms_output.put_line(' ' ||
g_emp_tab(i).ename);
-- Get next record
i := g_emp_tab.NEXT(i);
EXIT WHEN (i IS NULL);
END LOOP;
END IF;
END;
--
PROCEDURE run_global IS
-- Use g_emp_tab (global
definition)
l_emp_rec emp%ROWTYPE;
BEGIN
-- Initialize global table
FOR i IN 1 .. NofRecords LOOP
l_emp_rec.empno := i;
l_emp_rec.ename := 'NEW';
g_emp_tab(i) := l_emp_rec;
END LOOP;
-- Process global table
FOR i IN 1 .. NofRuns LOOP
process_global;
END LOOP;
END;
--
END plsql_tab;
/
When the parameters hold large data structures, all this copying slows down execution
and uses up memory. To prevent that, you can specify the NOCOPY hint in
Oracle8i, which allows the PL/SQL compiler to pass OUT and IN OUT parameters by
reference. Remember, NOCOPY is a hint, not a directive.
DECLARE
TYPE Numlist IS TABLE OF emp.empno%TYPE;
Id Numlist;
PROCEDURE GetEmp (pDeptNo IN NUMBER, pId
OUT NOCOPY Numlist) IS
BEGIN
SELECT empno BULK COLLECT INTO pId
FROM emp
WHERE deptno = pDeptNo;
END;
BEGIN
GetEmp(10,Id);
FOR i IN Id.FIRST..Id.LAST LOOP
dbms_output.put_line(Id(i));
END LOOP;
END;
/
Speed up your transactions with PL/SQL
tables
Datawarehouse Applications often process several millions rows, often each record is
selected, processed and updated again in the database. This can be a very time
consuming task. If you can split to whole transaction in smaller pieces and your
machine have enough physical memory use PL/SQL tables, which are kept in-memory. Select
all needed rows and insert them into the in-memory PL/SQL table. Then analyze, group or
process them directly in the memory, finally write back the whole PL/SQL table to the
databse.
In one of our DSS application, we used this approach, the performance gain is
incredible. 20'000 records has been processed 100 - 150 times faster with PL/SQL than
the direct method (each record separate from / to the database). One further advantage
is, that the transaction is less longer open. One disadvantage of PL/SQL tables is,
that you have to use one BINARY INTEGER as the key for the table, real primary keys
cannot be used in PL/SQL tables. Therefore you have to create an artificial key, based
on the real primary key.
To demonstrate this performance gain, we use a simple SELECT, PROCESS, UPDATE
transaction, first processing row by row, then using a PL/SQL table.
--
-- PL/SQL-Update
--
SET SERVEROUTPUT ON;
--
DECLARE
CURSOR check_reload_cur (p_dst_id statreload.dst_id%TYPE) IS
SELECT 'X'
FROM statreload
WHERE dst_id = p_dst_id;
--
NofRecords CONSTANT NUMBER := 20000;
NofKeys CONSTANT NUMBER := 500;
--
hashKey NUMBER(15);
i NUMBER(15);
l_dummy CHAR(1);
--
BEGIN
-- Clear table STATRELOAD
DELETE FROM statreload;
-- Process records
FOR i IN 1..NofRecords LOOP
BEGIN
hashKey := MOD(i, NofKeys);
-- If record has already processed
update
-- the result, else insert it.
OPEN check_reload_cur (hashKey);
FETCH check_reload_cur INTO l_dummy;
IF (check_reload_cur%FOUND) THEN
UPDATE statreload SET
sum_weekday = sum_weekday + hashKey,
sum_weekend = sum_weekend + hashKey,
num_weekday = num_weekday + 1,
num_weekend = num_weekend + 1
WHERE dst_id = hashKey;
ELSE
INSERT INTO statreload (
day, tim_id, chl_id, csh_id, dst_id,
srv_id, rld_id,
sum_weekday, sum_weekend,
num_weekday,
num_weekend, trusted
) VALUES (
TRUNC(SYSDATE), 1, 1, 1, hashKey, 1, 1,
hashKey, hashKey, 1, 1, 0);
END IF;
CLOSE check_reload_cur;
END;
END LOOP;
COMMIT;
END;
/
--
-- PL/SQL-Tabelle
--
SET SERVEROUTPUT ON;
--
DECLARE
TYPE t_reload IS TABLE OF statreload%ROWTYPE
INDEX BY BINARY_INTEGER;
tab_reload t_reload;
--
NofRecords CONSTANT NUMBER := 20000;
NofKeys CONSTANT NUMBER := 500;
--
hashKey NUMBER(15);
i NUMBER(15);
--
BEGIN
-- Process records
FOR i IN 1..NofRecords LOOP
BEGIN
hashKey := MOD(i, NofKeys);
IF (tab_reload.EXISTS(hashKey)) THEN
-- Update temp. table
tab_reload(hashKey).sum_weekday :=
tab_reload(hashKey).sum_weekday + hashKey;
tab_reload(hashKey).sum_weekend :=
tab_reload(hashKey).sum_weekend + hashKey;
tab_reload(hashKey).num_weekday :=
tab_reload(hashKey).num_weekday + 1;
tab_reload(hashKey).num_weekend :=
tab_reload(hashKey).num_weekend + 1;
ELSE
-- Insert temp.
table
tab_reload(hashKey).sum_weekday :=
hashKey;
tab_reload(hashKey).sum_weekend :=
hashKey;
tab_reload(hashKey).num_weekday := 1;
tab_reload(hashKey).num_weekend := 1;
END IF;
END;
END LOOP;
-- Clear table STATRELOAD
DELETE FROM statreload;
-- Insert into table STATRELOAD
i := tab_reload.FIRST;
IF (NOT i IS NULL) THEN
LOOP
INSERT INTO statreload (day, tim_id, chl_id,
csh_id, dst_id, srv_id, rld_id,
sum_weekday,
sum_weekend, num_weekday, num_weekend,
trusted)
VALUES (TRUNC(SYSDATE), 1, 1, 1, i, 1, 1,
tab_reload(i).sum_weekday,
tab_reload(i).sum_weekend,
tab_reload(i).num_weekday,
tab_reload(i).num_weekend,0);
i := tab_reload.NEXT(i);
EXIT WHEN (i IS NULL);
END LOOP;
ELSE
dbms_output.put_line('No records to update!');
END IF;
COMMIT;
END;
/
How to migrate LONG fields into VARCHAR2
In Oracle7 the LONG datatype often cause difficulties, for example a table in Oracle7
can have only one LONG, LONG's couldn't replicated and more. We have seen, that in many
cases simple text is inserted in these LONG fields. Due to this, we suggest to convert
the LONGs into VARCHAR2 with the following simple PL/SQL script. In Oracle8 you may
specify a longer VARCHAR2 (40000).
CREATE TABLE long_tab (
long_field LONG
);
ALTER TABLE long_tab ADD (char_field VARCHAR2(2000));
CREATE OR REPLACE PROCEDURE long2varchar IS
CURSOR getrowid IS
SELECT rowid, long_field
FROM long_tab;
BEGIN
FOR rec IN getrowid LOOP
UPDATE long_tab
SET char_field = rec.long_field;
END LOOP;
COMMIT;
END;
/
EXECUTE long2varchar;
Tracing other user sessions
If you want to look or trace at a certain oracle process, belonging to an Orcale User,
the best way is to trace the session for this user. As a DBA, you can trace other
sessions, normal users can only trace their own sessions.
1). Enable TIMED statistics
ALTER SESSION SET TIMED_STATISTICS = TRUE;
However, most Oracle systems have this INIT.ORA parameter already set to TRUE,
because the performance loss is small.
2). Get SID and Serial#
SELECT s.sid,s.serial#,p.pid,p.program
FROM v$session s, v$process p
WHERE s.paddr = p.addr;
3). Stop the process
EXEC dbms_system.sql_trace_in_session(sid,serial,true);
Then use TKPROF in USER_DUMP_DEST with the generated trace file.
How to start an Oracle
database with corrupted or lost dbfile ?
Help -- we cannot start the Oracle Database ... we get an error message telling us,
that one datafile is lost or corrupted ... what can we do ?
ORA-01157: cannot identify/lock data file 10 - see DBWR trace file
ORA-01110: data file 10: '/u01/db/test.dbf'
If the database is in ARCHIVELOG mode with a working online backup concept you are a
lucky person, recover the database and everything is OK. But what can we do, if the
database is in NOARCHIVELOG mode and no backup is present ?
1). Switch the damaged datafile to the RECOVER status
svrmgr> ALTER DATABASE DATAFILE '/u01/db/test.dbf' OFFLINE DROP;
svrmgr> SELECT file#,status,bytes,name FROM v$datafile;
FILE# STATUS BYTES NAME
------- -------- --------- ------------------------------
1 SYSTEM 104857600
/u01/db/SOL3/sys/SOL3_sys1.dbf
2 RECOVER 2097152
/u01/db/test.dbf
2). Stop and Start the database to verify that the database can be started without '
test.dbf '.
svrmgr> SHUTDOWN IMMEDIATE;
svrmgr> STARTUP;
3). DROP the tablespace to which the datafile belongs
svrmgr> DROP TABLESPACE test INCLUDING CONTENTS;
The database can only be stopped with SHUTDOWN ABORT with a damaged or lost datafile
and the datafile is still in ONLINE mode. Therefore it's better to switch the datafile
to the RECOVER status as shown above before stopping the database. However there is a
way to switch the datafile to the RECOVER status when the database is stopped.
1). Mount the database and switch the damaged datafile to the RECOVER status
svrmgr> STARTUP MOUNT;
svrmgr> ALTER DATABASE DATAFILE '/u01/db/test.dbf' OFFLINE
DROP;
svrmgr> ALTER DATABASE OPEN;
2). DROP the tablespace to which the datafile belongs
svrmgr> DROP TABLESPACE test INCLUDING CONTENTS;
3). Stop and Start the database to verify that the database can be started without '
test.dbf '.
svrmgr> SHUTDOWN IMMEDIATE;
svrmgr> STARTUP;
-
The term ' OFFLINE DROP ' is misleading, it is not possible to drop a datafile with
this command. The only purpose of this command is to startup a database with
damaged or missing datafile and the databae is in NOARCHIVELOG mode.
-
The command ' ALTER DATABASE DATAFILE ... OFFLINE DROP ' changes the datafile
status from ONLINE to RECOVER. In this mode, the database can be started even if
the datafile is not present.
-
If space management (e.g. CREATE TABLE ..) occurs for this datafile, Oracle will
try to allocate space in this ' dropped ' datafile and fails.
-
The only way to drop a datafile is to drop the tablespace to which the datafile
belongs. Unfortunately you will lose data if you don't have an actual backup.
How to drop a tablespace
containing tables with references ?
You cannot drop a tablespace containing tables with active referential integrity
constraints.
SQL> DROP TABLESPACE test1 INCLUDING CONTENTS;
ORA-02449: unique/primary keys in table referenced by foreign keys
Before you can drop the tablespace you have to to drop or disable the referential
integrity constraints. You can verify the tables with references to tables in other
tablespaces.
Let's create an example.
CREATE TABLESPACE test1 datafile '/u01/db/test1.dbf' SIZE 2M REUSE;
CREATE TABLESPACE test2 datafile '/u01/db/test2.dbf' SIZE 2M REUSE;
CREATE TABLE test1 (
id1 NUMBER(5) PRIMARY KEY,
val VARCHAR2(10)
)
TABLESPACE test1;
CREATE TABLE test2 (
id2 NUMBER(5) PRIMARY KEY,
id1 NUMBER(5) REFERENCES test1 (id1),
val VARCHAR2(10)
)
TABLESPACE test2;
SQL> ALTER TABLESPACE test1 OFFLINE;
SQL> DROP TABLESPACE test1 INCLUDING CONTENTS;
ORA-02449: unique/primary keys in table referenced by foreign keys
List the Primary- and Foreign Key Relationsships. The output of the SQL-Statement is
listed below, click here for the SQL-Statement.
From From
To To
Table Foreign
Foreign Primary Primary
Owner Tablespace Table Column Table
Column
----- ---------- -------- ------- -------- ----------
SCOTT TAB EMP
DEPTNO DEPT DEPTNO
TAB EMP
MGR EMP
EMPNO
TAB ITEM
ORDID ORD ORDID
TAB ORD
CUSTID CUSTOMER CUSTID
TAB ORD
CUSTID CUSTOMER CUSTID
TEST1 TEST2
ID1 TEST1 ID1
SELECT constraint_name,table_name
FROM dba_constraints
WHERE constraint_type = 'R'
AND table_name like upper ('%TEST%');
CONSTRAINT_NAME
TABLE_NAME
------------------------------ ------------------------------
SYS_C005395
TEST2
SQL> ALTER TABLE test2 DROP CONSTRAINT SYS_C005395;
SQL> DROP TABLESPACE test1 INCLUDING CONTENTS;
How to load EBCDIC data into an
Oracle database ?
Last week, we had to load EBCDIC data from an IBM host the an Oracle 8 Database. Well,
not a job we are doing every day, but with some hints from the Oracle Support an easy
task.
The "dd" Unix command can be used to convert EBCDIC data files to ASCII and
vice-versa.
For example:
dd if=data.ebc of=data.asc conv=ascii cbs=87
The example takes data.ebc as EBCDIC input file with a fixed record length of 86,
converts it into ASCII, and writes the converted output to file data.asc.
Specify the Characterset WE8EBCDIC500 for the EBCDIC data. The following example shows
the SQL*Loader Controlfile to load a fixed length EBCDIC record into the Oracle
Database.
LOAD DATA
CHARACTERSET WE8EBCDIC500
INFILE data.ebc "fix 86 buffers 1024"
BADFILE data.bad'
DISCARDFILE data.dsc'
REPLACE
INTO TABLE temp_data
(
field1 POSITION (1:4) INTEGER
EXTERNAL,
field2 POSITION (5:6) INTEGER
EXTERNAL,
field3 POSITION (7:12) INTEGER
EXTERNAL,
field4 POSITION (13:42) CHAR,
field5 POSITION (43:72) CHAR,
field6 POSITION (73:73) INTEGER EXTERNAL,
field7 POSITION (74:74) INTEGER EXTERNAL,
field8 POSITION (75:75) INTEGER EXTERNAL,
field9 POSITION (76:86) INTEGER EXTERNAL
)
How to show column and table comments ?
If you have to verify an unkown database schema, it can be very helpful to list the
table and column comments, specially if there is no documentation. Unfortunately, some
designers are too lazy to specify these comments using the following SQL statement:
COMMENT ON TABLE emp IS 'Employee Information';
COMMENT ON COLUMN emp.empno IS 'Employee Identification';
To generate a report with all column and table comments, you can use the following
simple SQL*Plus script -- click here to show the script.
The script generates the following output:
Table Comments
Table Table
Owner Name
Comments
----- --------------------- ---------------------------------------
SOL PRICE
A group of valid prices connections
RATE
Named rates that are applicable
Column Comments on Tabelle: PRICE
Table Column
Owner Name
Comments
----- --------------------- ---------------------------------------
SOL NAME
Name of the priceplan (UNIQUE)
DESCRIPTION
Description of the priceplan
The Mistery of Inline Views
One of the hidden features of Oracle, are the so called Inline Views (Immediate View,
View on the Fly, Anonymous View). They are very useful to overcome some restrictions
as:
-
Users want to use Views, but have no CREATE VIEW privilege.
-
A SELECT statement within CONNECT BY can select only one table.
Instead to create a view with CREATE VIEW, which needs the necessary privileges, you
can specify the view directly within the FROM clause. The following example, shows how
to print the number of rows from two tables in one line using an Inline View.
SELECT e.emp_count, d.dept_count
FROM (SELECT COUNT(*) emp_count FROM emp) e,
(SELECT COUNT(*) dept_count FROM dept)
d;
EMP_COUNT DEPT_COUNT
--------- ----------
14
4
Another example using an Inline View gives departments' total employees and salaries as
a decimal value of all the departments:
SELECT a.deptno "Department",
(a.num_emp/b.total_count)*100 "%Employees",
(a.sal_sum/b.total_sal)*100 "%Salary"
FROM (SELECT deptno, COUNT(*) num_emp, SUM(SAL) sal_sum
FROM emp
GROUP BY deptno) a,
(SELECT COUNT(*) total_count, SUM(sal)
total_sal
FROM emp) b;
Department %Employees %Salary
---------- ---------- ---------
10 21.428571 30.146425
20 35.714286 37.4677
30 42.857143 32.385874
The next example demonstrates how to overcome the restriction, that a SELECT statement
with a CONNECT BY to represent hierarchical dependencies, can specify only one table in
the FROM clause. There is no possibility to enter a JOIN directly in the FROM clause.
This problem can be solved with an Inline View. In the top SELECT list, all attributes
must be defined, including those within the Inline View.
COLUMN employee FORMAT A12 HEADING "Chart"
COLUMN empno FORMAT 9999 HEADING "EmpNo"
COLUMN job FORMAT A10 HEADING "Job"
COLUMN dname FORMAT A10 HEADING "Dept"
COLUMN mgr FORMAT A8 HEADING "Boss"
COLUMN sal FORMAT 9999 HEADING "Salary"
COLUMN mgrno FORMAT A6 HEADING "BossNo"
SELECT employee, empno, job, d.dname, mgr, sal, mgrno
FROM dept d,
(SELECT LPAD(' ',2*(LEVEL-1)) || ename
employee,
empno, job, deptno, PRIOR(ename) mgr, sal,
DECODE(LEVEL,1,NULL,PRIOR(empno)) mgrno
FROM emp
CONNECT BY PRIOR empno = mgr
START WITH job = 'PRESIDENT')
e
WHERE e.deptno = d.deptno;
Note, that the SELECT list corresponds with the Inline View (Attributtes without table
alias). The departement name (d.dname) does not exist within the Inline View, it is
directly selected in the table DEPT using the JOIN e.deptno = d.deptno in the WHERE
clause, outside the Inline View.
Chart EmpNo Job
Dept
Boss Salary BossNo
------------ ----- ---------- ---------- ------ ------ ------
KING 7839 PRESIDENT
ACCOUNTING 5000
JONES 7566 MANAGER
RESEARCH KING 2975 7839
SCOTT 7788 ANALYST
RESEARCH JONES 3000 7566
ADAMS 7876 CLERK
RESEARCH SCOTT 1100
7788
FORD 7902 ANALYST
RESEARCH JONE 3000 7566
SMITH 7369 CLERK
RESEARCH FORD 800
7902
BLAKE 7698 MANAGER SALES
KING 2850 7839
ALLEN 7499 SALESMAN SALES
BLAKE 1600 7698
WARD 7521 SALESMAN SALES
BLAKE 1250 7698
MARTIN 7654 SALESMAN SALES
BLAKE 1250 7698
TURNER 7844 SALESMAN SALES
BLAKE 1500 7698
JAMES 7900 CLERK
SALES BLAKE
950 7698
CLARK 7782 MANAGER
ACCOUNTING KING 2450 7839
MILLER 7934 CLERK
ACCOUNTING CLARK 1300 7782
Using PL/SQL to speed up UPDATEs
PL/SQL may provide an especially noticeable performance gain when you are running large
batch update jobs in which parent / child updating plays a role. Consider the scenario
in which the ACCOUNT (Parent) table is updated every night from the daily "collection"
table BOOKING (Child). There are about 10'000 rows in ACCOUNT and
approximarely 200 rows in BOOKING.
CREATE TABLE account (
acc_id NUMBER(6) NOT NULL,
balance NUMBER(15) NOT NULL,
CONSTRAINT pk_account PRIMARY KEY (acc_id));
CREATE TABLE booking (
bkg_id NUMBER(6) NOT NULL,
acc_id NUMBER(6) NOT NULL,
amount NUMBER(15) NOT NULL,
CONSTRAINT fk_booking_account
FOREIGN KEY (acc_id) REFERENCES account (acc_id),
CONSTRAINT pk_booking PRIMARY KEY (acc_id));
Using plain SQL may take several minutes, due the correlated subquery.
For Oracle < Version 8.1.5
UPDATE account A
SET A.balance = (SELECT B.amount + A.balance
FROM booking B
WHERE B.acc_id = A.acc_id)
WHERE EXISTS (SELECT 'X'
FROM booking B
WHERE B.acc_id = A.acc_id);
For Oracle >= Version 8.1.5
UPDATE account A
SET balance = balance + (SELECT amount
FROM booking B
WHERE B.acc_id = A.acc_id)
WHERE EXISTS (SELECT 'X'
FROM booking B
WHERE B.acc_id = A.acc_id);
Now suppose you use PL/SQL to achieve the same result. This may run in seconds.
DECLARE
CURSOR read_amount IS
SELECT acc_id, amount
FROM booking;
--
l_acc_id NUMBER (6);
l_amount NUMBER(15);
BEGIN
OPEN read_amount;
LOOP
FETCH read_amount INTO l_acc_id, l_amount;
EXIT WHEN read_amount%NOTFOUND;
--
UPDATE account A
SET balance = balance + l_amount
WHERE acc_id = l_acc_id;
END LOOP;
END;
Using PL/SQL instead of traditional SQL may result in a substantial performance gains,
however PL/SQL does not always produce such results. If the BOOKING table contains
1'000 or more rows, rather than 200, the result is different. If a child table
updates more than 10% to 15% of the parent table, PL/SQL will actually make the update
run more slowly. PL/SQL uses the table's indexes and performs more physical
reads against the database than plain SQL, which performs a full table scan in this
case. Always experiment with alternatives, benchmark the options, and question the
results.
How to cache a table in the SGA ?
In order to cache a table in the SGA it has to be smaller than
CACHE_SIZE_THRESHOLD as set in the init.ora file. However, the cost based
analyzer doesn't take table cacheing into account when doing optimization so you may
want to force the table using hints.
Optimize Table Structures with CAS
and ORDER BY
Specify CREATE TABLE AS SELECT ORDER BY if you intend to create an index on the same
key as the ORDER BY key column. Oracle will cluster data on the ORDER BY key so that it
corresponds to the index key. With this "trick", the COST based Optimizer will more
often use the index instead of performing a full table scan.
CREATE TABLE customer_reorg AS
SELECT * FROM customer ORDER BY name;
DROP TABLE customer;
RENAME customer_reorg TO customer;
CREATE INDEX idx_cust_name ON customer(name);
Creating Oracle 7 Export Files from
Oracle 8
You can create an Oracle release 7 export file from an Oracle8i
database by running Oracle release 7 Export against an Oracle8i
server. To do so, however, the user SYS must first run the CATEXP7.SQL script, which
creates the export views that make the database look, to Export, like an Oracle release
7 database.
The following steps describe the procedure in more detail:
-
Run the catexp7.sql script on the Oracle8i database. This script
is in the $ORACLE_HOME/rdbms/admin directory.
-
Use the Oracle7 Export utility to export the parts of the Oracle8i
database containing the new or changed data.
-
Use the Oracle7 Import utility to import the file previously
exported from the Oracle8i database into the restored Oracle7 database.
How to remove in-doubt transactions ?
In doubt transactions may occur at double phase commit time for network, break node ...
reason. Normally if a double phase commit failed, you may have some entries in views
DBA_2PC_PENDING and DBA_2PC_NEIGHBORS. To force the in doubt transaction to rollback
you have to use the command:
ROLLBACK FORCE <transaction_id>;
Unfortunately, sometime the entries are still there ... and you may discover in your
alert<sid>.log file something like: ora-600 [18104] ... This point to bug 445604
Fixes in version Oracle 7.3.4. Now it's possible to use package DBMS_TRANSACTION to
solve the problem if rollback force do not clean all entries.
Do as follow:
EXECUTE DBMS_TRANSACTION.PURGE_LOST_DB_ENTRY('xid');
Where 'xid' come from: SELECT local_tran_id FROM DBA_2PC_PENDING;
How to install the Help-Tables
for SQL*Plus and PL/SQL ?
It can be handy to have the Help-Tables for SQL*PLUS online using SQL>help
command. Usually, these tables in $ORACLE_HOME/sqlplus/admin/help are not
installed per default, but it's easy done with the following Shell-Script.
#!/bin/sh
$ORACLE_HOME/bin/svrmgrl << EOF
connect system/manager
@$ORACLE_HOME/sqlplus/admin/help/helptbl.sql;
exit;
EOF
$ORACLE_HOME/bin/svrmgrl << EOF
connect system/manager
@$ORACLE_HOME/sqlplus/admin/help/helpindx.sql;
exit;
EOF
cd $ORACLE_HOME/sqlplus/admin/help
$ORACLE_HOME/bin/sqlldr userid=system/manager control=plushelp.ctl
$ORACLE_HOME/bin/sqlldr userid=system/manager control=plshelp.ctl
$ORACLE_HOME/bin/sqlldr userid=system/manager control=sqlhelp.ctl
How much Redo-Log does this
Transaction generate ?
The Oracle Dicitonry is a wonderful Pool of many hidden resorces. In the Oracle System
Statistic Table V$SYSSTAT you can find the Number of blocks written to the Redo. This
can be found in the Attribute STATISTIC# = 71. If you measure this value before and
after the transaction, you can approximately find out how much Redo-Log the transaction
generates. Of course this is approximately, because there may exists other transactions
at the same time.
SQL> select * from v$sysstat where statistic#=71;
STATISTIC# NAME
---------- ----------------------------------------
71 physical writes direct
Example
SQL> select value from v$sysstat where statistic#=71;
VALUE
---------
436
SQL> create table myhelp as select * from system.help;
Table created.
SQL> select value from v$sysstat where statistic#=71;
VALUE
---------
642
Flush Shared Pool when it
reaches 60-70% of it's capacity
On a recent project we had a problem where performance would start acceptable at the
beginning of the day and by mid-day would be totally unacceptable. Investigation showed
that the third party application that ran on top of the Oracle database was generating
ad hoc SQL without using bind variables. This generation of ad hoc SQL and non-use of
bind variables was resulting in proliferation of non-reusable code fragments in the
shared pool, one user had over
90 shared pool segments assigned for queries that differed only by the selection
parameter (for example "where last_name='SMITH'" instead of "where last_name='JONES'").
This proliferation of multiple nearly identical SQL statements meant that for each
query issued the time to scan the shared pool for identical statements was increasing
for each non-reusable statement generated.
A flush of the shared pool was the only solution to solve this performance problem,
resulting that all other query returned again in less than a second.
It was determined that an automatic procedure was needed to monitor the shared pool and
flush it when it reached 60-70% of capacity.
The following procedue was created:
CREATE OR REPLACE VIEW sys.sql_summary AS SELECT
username,
sharable_mem,
persistent_mem,
runtime_mem
FROM sys.v_$sqlarea a, dba_users b
WHERE a.parsing_user_id = b.user_id;
CREATE OR REPLACE PROCEDURE sys.flush_it AS
CURSOR get_share IS
SELECT SUM(sharable_mem)
FROM sys.sql_summary;
CURSOR get_var IS
SELECT value
FROM v$sga
WHERE name like 'Var%';
CURSOR get_time is
SELECT SYSDATE
FROM dual;
todays_date DATE;
mem_ratio NUMBER;
share_mem NUMBER;
variable_mem NUMBER;
cur INTEGER;
sql_com VARCHAR2(60);
row_proc NUMBER;
BEGIN
OPEN get_share;
OPEN get_var;
FETCH get_share INTO share_mem;
DBMS_OUTPUT.PUT_LINE('share_mem: '||to_char(share_mem));
FETCH get_var INTO variable_mem;
DBMS_OUTPUT.PUT_LINE('variable_mem: '||to_char(variable_mem));
mem_ratio:=share_mem/variable_mem;
DBMS_OUTPUT.PUT_LINE('mem_ratio: '||to_char(mem_ratio));
IF (mem_ratio>0.3) THEN
DBMS_OUTPUT.PUT_LINE ('Flushing Shared Pool ...');
cur:=DBMS_SQL.open_cursor;
sql_com:='ALTER SYSTEM FLUSH SHARED_POOL';
DBMS_SQL.PARSE(cur,sql_com,dbms_sql.v7);
row_proc:=DBMS_SQL.EXECUTE(cur);
DBMS_SQL.CLOSE_CURSOR(cur);
END IF;
END;
/
This procedure was then loaded into the job queue and scheduled to run every hour using
the following commands:
DECLARE
job NUMBER;
BEGIN
DBMS_JOB.SUBMIT(job,'flush_it;',sysdate,'sysdate+1/24');
END;
/
Show who am I with my environment
set termout off
set head off
set termout on
select 'User: '|| user || ' on database ' || global_name,
'(Terminal='||USERENV('TERMINAL')||
', Session-Id='||USERENV('SESSIONID')||')'
from global_name;
User: SCOTT on database ARK1.WORLD
(Terminal=ARKUM, Session-Id=150)
Check current ROLE for Database Access
When a user logs on, Oracle enables all privileges granted explicitly to the user and
all privileges in the user's default roles. During the session, the user or an
application can use the SET ROLE statement any number of times to change the roles
currently enabled for the session. The number of roles that can be concurrently enabled
is limited by the initialization parameter MAX_ENABLED_ROLES. You can see which roles
are currently enabled by examining the SESSION_ROLES data dictionary view, for example:
SELECT role FROM session_roles;
ROLE
------------------------------
CONNECT
RESOURCE
You may check the DB access in your application context using the following code
construct.
DECLARE
HasAccess BOOLEAN := FALSE;
CURSOR cur_get_role IS
SELECT role FROM session_roles;
BEGIN
FOR role_rec IN cur_get_role LOOP
IF (UPPER(role_rec.role) IN ('ADMIN','CLERK')) THEN
HasAccess := TRUE;
END IF;
END LOOP;
IF (NOT HasAccess) THEN
RAISE_APPLICATION_ERROR
(-20020,'Sorry, you have no access to the database');
END IF;
END;
/
Useful UNIX Utilities to
manipulate fixed length records
The Unix operating system has a number of utilities that can be very useful for
pre-processing data files to be loaded
with SQL*Loader. Even when the same functionality can be achieved through
SQL*Loader, the utilities described here will be much faster. Data warehousing
applications, in particular, can benefit greatly from these utilities.
This article describes such Unix commands with examples of their utilization. The Unix
version of reference here is Sun Solaris, which is based on Unix System V Release 4.
For syntax details and the full range of options for each command, consult the man
pages in your system and your operating system documentation.
EXAMPLE 1
Let us assume a load with the following SQL*Loader control file:
LOAD DATA
INFILE 'example1.dat'
INTO TABLE emp
(empno POSITION(01:04) INTEGER
EXTERNAL,
ename POSITION(06:14)
CHAR,
job
POSITION(16:24)
CHAR,
mgr
POSITION(26:29)
INTEGER EXTERNAL,
sal
POSITION(31:37)
DECIMAL EXTERNAL,
comm POSITION(39:42)
DECIMAL EXTERNAL,
deptno POSITION(44:45) INTEGER
EXTERNAL)
Here are the contents of data file example1.dat:
7782 CLARK MANAGER 7839 2572.50 0.20 10
7839 KING PRESIDENT
5850.00 10
7654 MARTIN SALESMAN 7698 1894.00 0.15 30
EXAMPLE 2
Let us assume another load with the following control file:
LOAD DATA
INFILE 'example2.dat'
INTO TABLE dept
FIELDS TERMINATED BY ',' OPTIONALLY ENCLOSED BY '"'
(deptno, dname, loc)
Below are the contents of data file example2.dat:
12,RESEARCH,"SARATOGA"
10,"ACCOUNTING",CLEVELAND
13,"FINANCE","BOSTON"
The performance of direct path loads can be significantly improved by presorting the
input data on indexed columns.
Pre-sorting minimizes the demand for temporary segments during the load.
The Unix command to be used for presorting is "sort".
In Example 1, suppose you have added the SORTED INDEXES (empno) clause to the control
file to indicate that fields in the data file are presorted on the EMPNO column.
To do that presorting, you would enter at the Unix prompt:
sort +0 -1 example1.dat > example1.srt
This will sort file example1.dat by its first field (by default fields are delimited by
spaces and tabs) and send the output to file example1.srt:
7654 MARTIN SALESMAN 7698 1894.00 0.15 30
7782 CLARK MANAGER 7839 2572.50 0.20 10
7839 KING PRESIDENT
5850.00 10
In Example 2, if you wanted to sort file example2.dat by column DNAME, you would enter:
sort -t, -d +1 -2 example2.dat > example2.srt
where "-t," indicates that commas are delimiters, "-d" causes sort to consider only
letters and digits in comparisons, and example2.srt is the output file:
10,"ACCOUNTING",CLEVELAND
13,"FINANCE","BOSTON"
12,RESEARCH,"SARATOGA"
Often, it is necessary to remove one or more fields from all the records in the data
file. The Unix command that does that is "cut". In Example 1, if you want to
eliminate the COMM field altogether from the data file, enter at the Unix prompt:
cut -c1-38,44- example1.dat > example1.cut
where the "-c" option specifies the character ranges that you want to extract from each
record. The output file example1.cut contains:
7782 CLARK MANAGER 7839 2572.50 10
7839 KING PRESIDENT
5850.00 10
7654 MARTIN SALESMAN 7698 1894.00 30
In Example 2, to eliminate the LOC field from the data file, you would enter:
cut -f1-2 -d, example2.dat > example2.cut
where "-f1-2" indicates you want to extract the first two fields of each record and
"-d," tells cut to treat comma as a delimiter. The output file example2.cut would
contain:
12,RESEARCH
10,"ACCOUNTING"
13,"FINANCE"
Two Unix commands can be used here: "tr" or "sed". For instance, if you want to replace
all double quotes in the data file in Example 2 by single quotes, you may enter:
cat example2.dat | tr \" \' > example2.sqt
The piped "cat" is necessary because tr's input source is the standard input.
Single and double quotes are preceded by backslashes because they are special
characters. The output file will be:
12,RESEARCH,'SARATOGA'
10,'ACCOUNTING',CLEVELAND
13,'FINANCE','BOSTON'
Similarly, to substitute colons for commas as delimiters in Example 2, you may enter:
sed 's/,/:/g' example2.dat > example2.cln
The output would be:
12:RESEARCH:"SARATOGA"
10:"ACCOUNTING":CLEVELAND
13:"FINANCE":"BOSTON"
Just as for replacing characters, "tr" and "sed" can be used for eliminating them from
the data file. If you want to remove all double quotes from the data file in Example 2,
you may type:
cat example2.dat | tr -d \" > example2.noq
The contents of file example2.dat are piped to the tr process, in which the "-d" option
stands for "delete". The output file example2.noq would look like:
12,RESEARCH,SARATOGA
10,ACCOUNTING,CLEVELAND
13,FINANCE,BOSTON
An identical result would be obtained by using sed:
sed 's/\"//g' example2.dat > example2.noq
The string in single quotes indicates that double quotes should be replaced by an empty
string globally in the input file. Another interesting usage of tr would be to squeeze
multiple blanks between fields down to a single space character. That can be
achieved by doing:
cat example1.dat | tr -s ' ' ' ' > example1.sqz
The output file would look like:
7782 CLARK MANAGER 7839 2572.50 0.20 10
7839 KING PRESIDENT 5850.00 10
7654 MARTIN SALESMAN 7698 1894.00 0.15 30
Inserting characters into the data file
A typical situation in which you may need to insert characters into the datafile would
be to convert a fixed position data file into a delimited one. The data file in
Example 1 is a fixed position one. To convert it into a file delimited by commas,
you would enter
cat example1.dat | tr -s ' ' ',' > example1.dlm
and obtain
7782,CLARK,MANAGER,7839,2572.50,0.20,10
7839,KING,PRESIDENT,5850.00,10
7654,MARTIN,SALESMAN,7698,1894.00,0.15,30
Merging different files into a single data file
Merging can be done by using "paste". This command allows you to specify a list
of files to be merged and the character(s) to be used as delimiter(s). For
instance, to merge the data files in Examples 1 and 2, you may enter:
paste -d' ' example1.dat example2.dat > example.mrg
where "-d' '" specifies a blank character as the delimiter between records being merged
and example.mrg is the merged output file:
7782 CLARK MANAGER 7839 2572.50 0.20 10
12,RESEARCH,"SARATOGA"
7839 KING PRESIDENT
5850.00 10 10,"ACCOUNTING",CLEVELAND
7654 MARTIN SALESMAN 7698 1894.00 0.15 30
13,"FINANCE","BOSTON"
The Unix command for this is "uniq". It eliminates or reports consecutive lines
that are identical. Because only adjacent lines are compared, you may have to use
the sort utility before using uniq. In Example1, suppose you wanted to keep only the
first entry with DEPTNO = 10. The Unix command would be:
uniq +43 example1.dat > example1.unq
The "+43" indicates that the first 43 characters in each record should be ignored for
the comparison. The output file example1.unq would contain:
7782 CLARK MANAGER 7839 2572.50 0.20 10
7654 MARTIN SALESMAN 7698 1894.00 0.15 30
Use "wc". For example:
wc -l example1.dat
3 example1.dat
which indicates that the file contains three lines.
The "dd" Unix command can be used to convert EBCDIC data files to ASCII and
vice-versa. For example:
dd if=example1.ebc cbs=86 conv=ascii > example1.asc
takes example1.ebc as EBCDIC input file, converts it into ASCII, and writes the
converted output to file example1.asc.
The "dd" and "tr" commands can also be used for converting between uppercase and
lowercase characters. Because Oracle is currently case-sensitive, this can be
useful in many situations. For example, to convert all characters in file example1.dat
from uppercase to lowercase, simply enter
dd if=example1.dat conv=lcase > example1.low
or
cat example1.dat | tr "[A-Z]" "[a-z]" > example1.low
The contents of output file example1.low will be:
7782 clark manager 7839 2572.50 0.20 10
7839 king president
5850.00 10
7654 martin salesman 7698 1894.00 0.15 30
To convert this file back to uppercase characters, type
dd if=example1.low conv=ucase > example1.dat
or
cat example1.low | tr "[a-z]" "[A-Z]" > example1.dat
Why to use locally managed tablespaces ?
A tablespace that manages its own extents maintains a bitmap in each datafile to keep
track of the free or used status of blocks in that datafile. Each bit in the bitmap
corresponds to a block or a group of blocks. When an extent is allocated or freed for
reuse, Oracle changes the bitmap values to show the new status of the blocks. These
changes do not generate rollback information because they do not update tables in
the data dictionary.
Local management of extents automatically tracks adjacent free space, eliminating
the need to coalesce free extents. The sizes of extents that are managed locally
can be determined automatically by the system. Alternatively, all extents can have the
same size in a locally-managed tablespace.
A tablespace that manages its extents locally can have either uniform extent sizes or
variable extent sizes that are determined automatically by the system. When you create
the tablespace, the UNIFORM or AUTOALLOCATE (system-managed) option specifies the type
of allocation.
For system-managed extents, you can specify the size of the initial extent and Oracle
determines the optimal size of additional extents, with a minimum extent size of 64 KB.
This is the default for permanent tablespaces.
For uniform extents, you can specify an extent size or use the default size, which is 1
MB. Temporary tablespaces that manage their extents locally can only use this type
of allocation.
The storage parameters NEXT, PCTINCREASE, MINEXTENTS, MAXEXTENTS, and DEFAULT
STORAGE are not valid for extents that are managed locally. Actually, you cannot
create a locally managed SYSTEM tablespace. Locally managed temporary tablespaces
must of type "temporary" (not "permanent").
Local management of extents avoids recursive space management operations, which can
occur in dictionary-managed tablespaces if consuming or releasing space in an extent
results in another operation that consumes or releases space in a rollback segment or
data dictionary table. Local management of extents automatically tracks adjacent free
space, eliminating the need to coalesce free extents.
Example:
-
An insert causes a request for an extent
-
Oracle allocates space in the data tablespace
-
This causes an update of system tables in the data
dictionary if tablespace is dictionary-managed
-
Consequently, an update is made to the redo log.
So a large number of inserts in to a tablespace with a small extent size may cause many
I/O's to the system tablespace and consequently the redo log fil |
